TECHNICAL INFORMATION
EN
2.1 General description of the engine
- 4-stroke, in-line cylinders Diesel engine;
- Liquid-cooling system;
- 4 valves per cylinder with hydraulic tappets;
- Turbocharger with Waste-gate valve;
- Common Rail - Direct injection.
2.2 Engine specifications
TECHNICAL DATA
UNIT
OF MEASURE
Engine type
KDI 3404 TM
cylinders n. 4
bore mm 96
stroke mm 116
displacement cm3 3359
max inclination during operation
(even in combined)
degree 40° max. 30 minutes
degree 45° max.1 minute
oil capacity (MAX
level.)
including oil filter
standard version lt. 15.6
dry weight Kg 405
2.3 Engine dimensions (mm)
ED0053030120
