Kohler KDI 3404TM Owner's Manual

5
27
_08.1
D2
D1
P
A
B
B
B
A
5.8
5.9
5.10
INFORMATION ABOUT MAINTENANCE
EN
5.8 Check Poly-V alternator belt
NOTE: The poly-v belt is not adjustable.
1. Check the belt A condition, if worn out or deteriorated,
replace it.
NOTE: Make sure that the ribs of the belt A are
inserted correctly into the grooves of the
pulleys B (as shown in D1 and D2).
2. Start the engine and run it for some minutes, then turn
off it, and let it cool down at ambient temperature.Check
by the appropriate tool that at point p the tension value is
between 149 and 196 Hz.
NOTE: If the poly-v belt tension results out
of the above mentioned values contact
KOHLER authorised workshops for
replacement.
5.9 Control water filter cartridge fuel
1. Gently loosen the wing screw A without removing it.
2. Drain the water if present.
3. Re-tighten the wing screw A as soon as the fuel begins
to flow.
5.10 Product preservation
Important
• If the engines are not to be used for 6 months, they must
be protected by carrying out the operations described in
Engine storage (up to 6 months) (Par. 5.11).
• If the engine is still not in use after the first 6 months, it
is necessary to carry out a further operation to extend the
protection period (more than 6 months) (Par. 5.12).
• If the engine is not to be used for an extended period, the
protective treatment procedure must be repeated within 24
months of the previous one.
5.11 Engine storage up to 6 months
Before storing the engine check that:
• The environments are not humid or exposed to bad weather.
Cover the engine with a proper protective sheet against
dampness and atmospheric contaminants.
• The place is not near electric panel.
• Avoid storing the engine in direct contact with the ground.
ED0053030120
