Kohler KDW 1003

- 28 -
KD 702_1003_1404 Workshop Manual_cod. ED0053029340_1° ed_ rev. 00
3
Technical information
OVERALL DIMENSION
KDW 702
A
B C
178.85 (7.04) 197.85 (7.78)122.25 (4.81)
DIMENSIONS mm (in.) - DIMENSIONI mm - MESURES mm - EINBAUMAßE mm - DIMENSIONE mm - DIMEN0ÇÕES mm
A
B
DIMENSIONS mm (in.) - DIMENSIONI mm - MESURES mm - EINBAUMAßE mm - DIMENSIONE mm - DIMEN0ÇÕES mm
C
D
515.5 (20.3)
351.5 (13.84)
E
F
269.2 (10.6)
242.5 (9.55)
I
L
204 (8.03)
421 (16.57)
G
H
O
P
186 (7.32)
367 (14.45)
169.5 (6.67)
484.5 (19.07)
M
N
418 (16.46)
150 (5.90)
359 (14.13)
165 (6.5)
