- 29 -
KD 702_1003_1404 Workshop Manual_cod. ED0053029340_1° ed_
3
Technical information
LDW 1003
204 (8.03)
515.5 (20.3)
A
B
C
D
186 (7.32)
351.5
(13.84)
E
F
359 (14.13)
165 (6.5)
I
L
450 (17.72)
510 (20.08)
G
H
O
269.2
(10.6)
242.5 (9.54)
150 (5.90)
M
N
169.5
(6.67)
484.5 (19.07)
DIMENSIONS mm (in.) - DIMENSIONI mm - MESURES mm - EINBAUMAßE mm - DIMENSIONE mm - DIMENÇÕES mm
A
B C
178.85 (7.04)
192.5 (7.58)
122.25 (4.81)
D
197.85 (7.79)
DIMENSIONS mm (in.) - DIMENSIONI mm - MESURES mm - EINBAUMAßE mm - DIMENSIONE mm - DIMENÇÕES mm
COPPA OLIO STANDARD IN LAMIERA - CARTER D’HUILE EN TÔLE STANDARD - SHEET METAL STANDARD OIL SUMP -
STANDARD BLECHÖLWANNE - CÁRTER DE ACEITE STANDARD EN PLANCHA - CÁRTER DE ÓLEO STANDARD EM CHAPA
COPPA OLIO MAGGIORATA IN ALLUMINIO - CARTER D’HUILE SURDIMENSIONNÉ EN ALUMINIUM - OVERSIZE ALUMINIUM OIL SUMP - VERGRÖSSER-
TER ALUMINIUMÖLWANNE - CÁRTER DE ACEITE SOBREDIMENSIONADO EN ALUMINIO - CÁRTER DE ÓLEO AUMENTADO - EM ALUMINIO
