Kohler KG2204T

TP-6903 5/16a Diagnostic Troubleshooting Codes 41
P-Code SPN FMI Description Possible Cause Corrective Action
P2306 1270 5 Ignition Coil C Primary
Control Circuit Low
 No spark detected by
the ECM.
 Troubleshoot the ignition coil and
leads. Refer to Section 4.8.
 Check for a disconnected spark
plug lead.
 Check the spark plug lead
continuity.
 Check for worn spark plug
electrodes.
 Replace the spark plug.
 Replace the ignition coil. Refer to
the Section 5.8.
P2307 1270 6 Ignition Coil C Primary
Control Circuit High
 No spark detected by
the ECM.
 Troubleshoot the ignition coil and
leads. Refer to Section 4.8.
 Check for a disconnected spark
plug lead.
 Check the spark plug lead
continuity.
 Check for worn spark plug
electrodes.
 Replace the spark plug.
 Replace the ignition coil. Refer to
the Section 5.8.
P2308 1395 31 Ignition Coil C
Secondary Circuit
 No spark detected by
the ECM.
 Troubleshoot the ignition coil and
leads. Refer to Section 4.8.
 Check for a disconnected spark
plug lead.
 Check the spark plug lead
continuity.
 Check for worn spark plug
electrodes.
 Replace the spark plug.
 Replace the ignition coil. Refer to
the Section 5.8.
P2309 1271 5 Ignition Coil D Primary
Control Circuit Low
 No spark detected by
the ECM.
 Troubleshoot the ignition coil and
leads. Refer to Section 4.8.
 Check for a disconnected spark
plug lead.
 Check the spark plug lead
continuity.
 Check for worn spark plug
electrodes.
 Replace the spark plug.
 Replace the ignition coil. Refer to
the Section 5.8.
P2310 1271 6 Ignition Coil D Primary
Control Circuit High
 No spark detected by
the ECM.
 Troubleshoot the ignition coil and
leads. Refer to Section 4.8.
 Check for a disconnected spark
plug lead.
 Check the spark plug lead
continuity.
 Check for worn spark plug
electrodes.
 Replace the spark plug.
 Replace the ignition coil. Refer to
the Section 5.8.
