Kohler KSS Series User Manual

TP-6447 10/1210 Section 1 Product Description
1.3 Model Designation
Model
K: Kohler Transfer S witch
Controls
D: MPACt 1500
Microprocessor Controls, Automatic
F: MPACt 1500
Microprocessor Controls, Non-Automatic
Number of Poles/Wires
Enclosure
Mechanism
S: Specific-Breaker Rated
Transition
S: Specific-Breaker Rated
P: Programmed-Transition
Power Connections
S: Standard
C: 208 Volts/60 Hz
D: 220 Volts/50 Hz
F: 240 Volts/60 Hz
G: 380 Volts/50 Hz
H: 400 Volts/50 Hz
J: 416 Volts/50 Hz
K: 440 Volts/60 Hz
M: 480 Volts/60 Hz
P: 380 Volts/60 Hz
R: 220 Volts/60 Hz
Voltage/Frequency
N: 2-pole, 3-wire, solid neutral
T: 3-pole, 4-wire, solid neutral
V: 4-pole, 4-wire, switched neutral
A: NEMA 1[
B: NEMA 12
C: NEMA 3R
D: NEMA 4
F: NEMA 4X
G: Open unit
Model Controls Voltage Poles Enclosure Current Rating Connection
s
Mechanism Transition
Current Rating: Numbers indicate the current
rating of the switch in amperes:
[ NEMA 1 enclosure standard. Other types available
to order.
Record the transfer switch model designation in the boxes. The transfer switch model designation defines
characteristics and ratings as explained below.
Sample Model Designation: KSP-DCTA-0100S
] Standard--transition models only.
0040 ]
0080 ]
0100
0150
]
0200
0225
]
0260 ]
0400
0600
0800 ]
1000 ]

Kohler KSS Series Specifications

General

Brand	Kohler
Model	KSS Series
Category	Switch
Language	English
