Kohler KSS Series - Page 20

TP-6447 10/1220 Section 2 Installation
tp6225
1. Engine start terminal location
2. Auxiliary contacts
1
2
Figure 2-13 Engine Start and Auxiliary Contact
Locations, 40--225 Amp
Standard-Transition Switches
tp6225
1
1. Engine start terminal location
2. Auxiliary contacts
2
Figure 2-14 Engine Start and Auxiliary Contact
Locations, 400--600 Amp
Standard-Transition Switches
tp6447
1. Engine start connection
2. Auxiliary contacts
1
2
Figure 2-15 Engine Start and Auxiliary Contact
Locations, 800--1000 Amp
Standard-Transition Switches
