Atollspeed Touch Screen Series – Original Instructions
This document is property of Kolb Huizhou Ltd. 11
Technical Drawing Atollspeed 400H
Atollspeed 400H K02-4003T1S
A Steam discharge cover
B Temperature limiter
C Power cable
D Touch screen display
E USB
Dimension: 583(W) x 730(D) x 592(H) mm
Door open dimension: 583(W) x 935(D) x 592(H) mm
Baking chamber dimension: 450(W) x 350(D) x 200(H) mm
Standard Voltage: 380-400V/3Ph/PE/50 Hz
Optional Voltage: 415V (Specify on order)
Optional Frequency: 60 Hz (Specify on order)
Total power: 4.9 kW
Microwave input power: 3.2 kW
Heating power: 3.3 kW
Current: 16 A
Weight: 88 kg
Microwave frequency: 2.465 GHz
Circuit breaker: 3 x D20
Wiring: 5 x 2.5 mm²
