Koldfront WTC12001W Service Manual

8
No.
Part Name
No.
Part Name
1
Display assembly
21
Electrical heating box (for units with heat)
2
Front panel
23
Electronic control box assembly
3
Air outlet assembly
23.1
Capacitor
3.1
Air outlet
23.2
Electrical control box
3.2
Horizontal louver
23.3
Transformer
3.3
Connecting rod for louver
23.4
Mounting rack for main control panel
3.4
Horizontal louver
23.5
Main control board
4
Evaporator assembly
23.6
Power supply cord
4.1
Evaporator
23.7
Defrost temperature sensor
4.3
Capillary tube assembly
23.8
Room temperature sensor
5
Compressor exhaust pipe assembly
23.11
Compressor capacitor
6
Compressor
24
Electrical control box cover
7
Remote control
25
Water receiver tray
9
Condenser
26
Chassis assembly
10
Axial fan
28
Rear grill
11
Rear barrier assembly
28
Rear grill
13
Fan motor
30
Installation accessories
14
Front barrier assembly
30.1
Upper and lower shutter frame
15
Cabinet
30.2
Left and right shutter frame
16
Rear air duct foam
30.3
Air inlet grille
18
Centrifugal fan
30.4
Plastic Rear Guard
19
Front air duct foam
31
Filter guide
20
Air filter

Koldfront WTC12001W Specifications

General

Brand	Koldfront
Model	WTC12001W
Category	Air Conditioner
Language	English
