Preparations for Installation
Before you begin, make sure you have all the parts and tools necessary for installation.
Tools You May Need:
• Flat Screwdriver or Putty Knife • Phillips Screwdriver • Tape Measure • Level • Drill
Parts Supplied:
Note: You may need to contact an electrician if your room’s circuit is not able to power your unit.
Note: To avoid risk of injury and / or product / property damage, please take the following
precautions:
 Two or more people are needed to properly handle and install the unit.
 Use proper lifting and carrying techniques.
 Before installation, make sure to inspect the window and sill to ensure they are able to handle
the weight and size of this unit.
 Wearing protective gloves will help to avoid injury from sharp edges.
The parts below are intended to be used in conjunction with a Koldfront branded Wall
Sleeve.
Part Name Size Qty Included
Horizontal Insulation Seals 1” x
3
/
8
” x 25” 1
Vertical Insulation Seals 1” x
3
/
8
” x 14” 2
Horizontal Insulation Seals 1” x
3
/
4
” x 14” 2
Foam Support Blocks 1” x 1
1
/
2
” x 14” 2
Tapered Support Blocks 1” x 1” x 17” (tapered to ¾”) 2
Main Insulating Seal (stuffer seal) 1” x 1
1
/
2
” x 84” 1
Trim Frame (sides) 2
Trim Frame (top / bottom) 2
Ground Wire (green) 1
Toothed washers for grounding screw 2
Grounding Screw 1
Rear Louver Panel / Grille (aluminum) 1
Nuts (plastic) 4
Washers (for screws) 4
Screws 4
Additional and / or duplicate parts noted below have been included to allow for installation
into non-Koldfront branded Wall Sleeves or to accommodate non-standard installation
scenarios. Any unused parts may be discarded at your discretion.
Part Name Size Qty Included
Centering / Support Blocks 4
1
/
2
” x 3
1
/
2
” x1
1
/
2
” 4
Plastic Divider
1
/
8
” x 4
1
/
2
” x 14
1
/
2
” x 2
Horizontal Insulation Seals 1” x
3
/
8
” x 25” 2
1
