5
4WK07
4WK16
4WK23
AIR FILTER DATA (inches)
Width 15 3/4 18 18 24 24
Height 9 1/4 16 16 11 3/4 11 ¾
Thickness 1/2 1/2 1/2 1/2 ½
NET WEIGHT 83 124 125 183 183
SHIPPING WEIGHT 89 133 134 201 201
(A) Cooling Capacity Rating Test Conditions: Evaporator Air - 80F D.B./67F W.B.
Condenser Water - 85F E.W.T./95F L.W.T.
(B) Heating Capacity Rating Test Conditions: Evaporator Air - 70F D.B./60F W.B.
Condenser Water - 70F E.W.T.
(C) Time Delay Fuses and Circuit Breakers are recommended.
(D) Reverse cycle units require 50F minimum water inlet temperature during the heating cycle.
(E) Total pressure drop for unit with Water Regulating Valve is sum of Condenser Coil and Water Valve Pressure Drop.
* Also available in 208/230 volt.
