Koldwave Kompac 4WK07 - Specification and Electric Data

S:\Koldwave\Kompac 4-Series IOM
Koldwave 4830 Transport Drive Dallas, Texas 75247
www.koldwave.com
www.mestekparts.com
4
Specification and Electric Data
CAPACITY CODE 4WK07 4WK14 4WK16 4WK23 4WK26
CAPACITY DATA
Cooling Capacity (A) 7000 12500 16000 23200 26000
Heating Capacity (B) & (D) 7800 14200 17900 31000 31000
Evaporator-CFM @ 0.0 ESP 250 410 480 800 800
ELECTRICAL DATA
Volts (Single Phase) 115 115 115* 208/230 208/230
Amperes (Cooling) 8.00 11.60 13.00 12.70/11.80 12.70/11.80
Amperes (Heating) 7.5 10.80 13.00 12.50/11.50 12.50/11.50
Watts (Cooling) 897 1276 1684 2416 2708
Watts (Heating) 840 1301 1692 2839 2839
E.E.R. 7.80 9.80 9.50 9.60 9.60
C.O.P. 2.70 3.20 3.10 3.20 3.20
Fuse/Breaker amps 15 15 20 20 20
Compressor H.P. 1/2 1 1 1/4 2 2
Blower Motor H.P. 1/25 1/15 1/15 1/7 1/7
In Rush Current (amps) 40.00 71.50 95.50 72.90 72.90
CONDENSATE PUMP
Power Consumption with Pump on 30 30 30 30 30
Voltage 115 115 115 208/230 208/230
Maximum Discharge Lift (Feet) 19.5 19.5 19.5 19.5 19.5
CONDENSER WATER FLOW & PRESSURE DROP DATA (G)
GPM @ 85F E.W.T. 1.75 3.00 4.00 6.00 6.00
Cond. Coil delta P (P.S.I.) 1.40 3.00 5.30 6.80 6.80
Water Valve delta (P.S.I) 2.00 3.00 5.00 14.00 14.00
GPM @ 60F E.W.T. 100F L.W.T. 0.44 0.75 1.00 1.50 1.50
Cond. Coil delta P (P.S.I.) 0.60 0.80 1.00 0.80 0.80
Water Valve delta (P.S.I) 2.00 2.00 2.00 2.00 2.00
Max. Water Side Working Pressure/With Water Valve-150 P.S.I./Without Valve-400 P.S.I.
MISC. DATA
Evap. Coil-# of Rows 3 3 3 4 4
Coil Face Area (FT2) 0.83 1.20 1.20 1.90 1.90
Refrigerant Charge R-22 in oz. 14 20 22 39 39
DIMENSIONAL DATA (inches)
Height-With Casters 17 5/8 31 1/2 31 1/2 28 ¾ 28 ¾
Height-Without Casters n/a 29 1/8 29 1/8 26 3/8 26 3/8
Length 22 3/8 25 25 36 36
Depth 12 10 3/16 10 3/16 12 1/4 12 ¼
