4. ADJUST
Inspection of the collimating sight line (i angle) of the instrument.
(1) As Picture 1 displays, mount the instrument on a tripod between 2 staff which
is 50m away from each other. Divide the distance between A and B into 3 sessions
with the same distance.
(2) Level the instrument.
(3) Process:
Operation Procedure Operation Display
1. Select “Adjust” in the menu and
press [ENT].
2. Press [MEAS].
3. Press [ENT].
4. Press [MEAS].
[▲］or［▼］
［ENT］
[MEAS]
［ENT］
［MEAS］
Menu
►1.Measure
To Next Page
