1.2 Operation Keys & Functions
key name function
POW/MEAS
Power ON/OFF
measure
Power ON/OFF, and start to measure.
Power ON: press once;
Power OFF: hold on for 2 seconds.
MENU menu Return to the menu list.
DIST distance
measure
In measurement status, press it to start measure
the distance and display the distance.
↑↓ select Turn the page of menu list or data list.
→← number moving Turn the left or right page when viewing the
data, or move left or right in inputting status.
ENT enter To confirm the parameters or inputting data.
ESC ESC To escape from menu mode or any setting
mode. Also to go backspace to delete a
character in inputting mode.
0～9
number keys Inputting numbers.
－
Mode of setting
inverse staff
Use for inputting inverse staff. Set the inverse
staff. You should activate this function in
parameter setting first.
illumination Turn ON/OFF the illumination
.
decimal point Inputting a decimal point
1.3 Display
The display adopts dot matrix LCD, displaying 2 lines, with 16 characters in each.
LCD illumination ON/OFF.
By pressing
to turn ON or OFF the illumination. It is also available to set it in
instrument parameters.
Setting Contrast
There’re 9 degrees for the contrast. Please refer to parameter setting to know how
to set the contrast.
