12
110-0001063/A
AsuitablelocationfortheOperatingPanelmustbechosenbeforetheinstallationstarts.
Observethelimitationsduetothecablelengths.WerecommendthattheOperating
Panelispositionedinthesamephysicaldirectionasthedisplay,sothat"up"onthe
operatingpanelisthesameas"up"onthedisplay.Experiencehasshownthatthiswill
makeiteasiertousethetrackballontheoperatingpanelwhenyouwishtocontrol
thecursoronthedisplay.
Procedure
1Preparethelocationandthenecessarytools.
Note
Toallowfuturemaintenance,youmustmounttheunitwithitscablesandconnectors
availableforeasyaccess.
2Drillandcutthepanelopeningasshownindrawing476352.
3MounttheOperatingPanelusingthesuppliedhardware.
Thenecessarymountinghardware(fourscrews,fournutplatesandfourboltcovers)
aresuppliedinthestandarddelivery.
aPositionthefournutplatesshownintheillustration.
bUsea3mmAllenkeytofastenthefourspecialbolts.
cMounttheboltcoversinthefourcornersoftheOperatingPanel.
4ConnecttheUSBcabletotheOperatingPanel.
Note
Whenyouconnectthecable,makesurethatitisproperlysecured,andableto
withstandthevibrationandmovementsofthevessel.
SimradInstallationManual
