OperatingPanelconnectors(Mk3)

TheMk3OperatingPanelisconnectedtotheProcessorUnitwithaUSBcable.

ConnecttheUSBcabletoanavailablesocketontheProcessorUnit.

Tip

TheHT20470ProcessorUnitallowsyoutoenable"wake-uponUSB"functionality.

"Wake-uponUSB"meansthatyoucanturnonthesonarsystembyactivatinganyUSB

deviceconnectedtoacompatibleUSBport.Seetherelevantprocedure.

Relatedtopics

Cablelayoutandinterconnections,page16

SimradInstallationManual
