Kongsberg Simrad Mk3 - Installation; Installing the Operating Panel (Mk3)

110-0001063/A
11
Installation
Topics
InstallingtheOperatingPanel(Mk3),page11
476352OperatingPaneldimensions(Mk3),page13
InstallingtheOperatingPanel(Mk3)
TheOperatingPaneloffersallnecessarycontrolfunctionsfornormaloperation.The
OperatingPanelisnormallyplacedonthebridgenearthedisplay.
Prerequisites
Youmustbeequippedwithastandardsetoftools.Thistoolsetmustcomprisethe
normaltoolsforelectronicandelectromechanicaltasks.Thisincludesdifferent
screwdrivertypes,pliers,spanners,acablestripper,asolderingiron,etc.Eachtool
mustbeprovidedinvarioussizes.Werecommendthatalltoolsaredemagnetizedto
protectyourequipment.Dependingonthechoseninstallationmethod,additionaltools
mayberequired.
Context
Thesonarsystemsupportsseveraldifferentoperating
panels.
TheMk3OperatingPanelisconnectedtotheProcessor
UnitwithaUSBcable.Adedicatedpowersupplyunit
isnotrequired.
Tip
TheHT20470ProcessorUnitallowsyoutoenable"wake-uponUSB"functionality.
"Wake-uponUSB"meansthatyoucanturnonthesonarsystembyactivatinganyUSB
deviceconnectedtoacompatibleUSBport.
Installation
