110-0001063/A
7
Introduction
Topics
OperatingPanel,page7
Orderinformation,page8
Supportinformation,page8
OperatingPanel
TheoptionalOperatingPanelcontainsallnecessarycontrolfunctionsfornormal
operationofthesonarsystem.
ThecontrolsprovidedbytheOperatingPanelarearrangedinlogicalfunctionalgroups.
Thisoffersyouclearandeasyoperationwithfastaccesstokeyfunctionality.Allthe
functionalityprovidedbythesonarsystemcanbeaccessedusingthetrackballonthe
OperatingPanelandthemenusystemshowninthedisplaypresentation.
Thesonarsystemsupportsseveraldifferentoperating
panels.
TheMk3OperatingPanelisconnectedtotheProcessor
UnitwithaUSBcable.Adedicatedpowersupplyunit
isnotrequired.
Tip
TheHT20470ProcessorUnitallowsyoutoenable"wake-uponUSB"functionality.
"Wake-uponUSB"meansthatyoucanturnonthesonarsystembyactivatinganyUSB
deviceconnectedtoacompatibleUSBport.
