Aboutthismanual
Thepurposeofthispublicationistoprovidethedescriptionsandproceduresrequiredto
installtheMk3OperatingPanel.
Targetaudience
Thepublicationisintendedfortechnicalpersonnelsuchasskilledshipyardworkers,
electricians,qualiedengineersandnavalarchitects.Itisassumedthatyouunderstand
thegeneralprinciplesofmaritimeelectronicequipment.Youmustalsobefamiliarwith
theinstallationofelectronicandmechanicalproducts.Youareexpectedtohavebasic
mechanicalskillsandfamiliaritywithhandlingofsensitiveelectronicequipment.
Installationinstructions/Installationdrawings
Theinformationinthisdocumentmustberegardedasguidelinesandrecommendations.
Note
Theinstallationshipyardmustprovideallnecessarydesignandinstallationdrawings,as
wellastherelevantworkstandardsandmountingprocedures.
Ifrequired,alldocumentsprovidedbytheshipyardforthephysicalinstallationofthe
sonarsystemmustbeapprovedbythevessel’ snationalregistryandcorresponding
maritimeauthorityand/orclassicationsociety.Suchapprovalmustbeobtainedbefore
theinstallationcanbegin.Theshipownerandshipyarddoingtheinstallationare
responsibleforobtainingandpayingforsuchapproval.
KongsbergMaritimeASwillacceptnoresponsibilityforanydamageorinjurytothe
product,vesselorpersonnelcausedbyequipmentthathasbeenincorrectlyinstalledor
maintained,orbydrawings,instructionsorproceduresthathavenotbeenpreparedbyus.
Theoutlinedimensionsofthesonarreceiverfoundintherelevantchapterinthismanual.
Endusermanualsandsourcedrawings(normallyinAutoCadformat)canbedownloaded
fromourwebsite.
•https://www.kongsberg.com/sherysonar
Registeredtrademarks
Observetheregisteredtrademarksthatapply.
