Assigningfunctionstotherotaryswitches
ontheOperatingPanel(Mk3)
TheMk3OperatingPanelisttedwithtworotaryswitches.Theswitchesareidentied
withnumbers.Eachswitchcanbeassignedafunctionrelatedtorange,gain,bearing
ortilt.
Context
TheOperatingPanelpageisusedtoselectwhichphysicalhardwarepanelyouuse,andto
assignfunctionalitytotheprogrammablebuttons.ThispageislocatedintheInstallation
dialogbox.TheInstallationdialogboxislocatedontheSetupmenu.
Procedure
1OpentheSetupmenu.
2OntheSetupmenu,selectInstallation.
ObservethattheInstallationmenuopens.Thisdialogboxcontainsanumberof
pagesselectedfromthemenuontheleftside.
3OntheleftsideoftheInstallationdialogbox,selectOperatingPanel.
4SelectOperatingPanelMk3.
5UnderRotarySwitchOptions,assignoneRotatefunctiontoeachrotaryswitch
ontheOperatingPanel.
Theassignedfunctionisactivatedwhenyouturntherotaryswitch.
Thefollowingfunctionscanbeassigned:
HorizontalRange
ThisistherangesettingintheHorizontalview.
VerticalRange
ThisistherangesettingintheVerticalview.
InspectionRange
ThisistherangesettingintheInspectionview.
HorizontalRange2
ThisistherangesettinginthesecondHorizontalviewwhena"dual"
presentationmodeisused.
VerticalRange2
ThisistherangesettinginthesecondVerticalviewwhena"dual"presentation
modeisused.
