30
110-0001063/A
PlaneRange
ThisistherangesettinginthePlaneview.
ActivePingRange
Thisistherangesettinginthecurrentlyactiveview.
ActivePingGain
Thisisthegainsettinginthecurrentlyactiveview
ActivePingBearing
Thisisthebearingsettinginthecurrentlyactiveview.
ActivePingTilt
Thisisthetiltsettinginthecurrentlyactiveview
6AssignonePushfunctiontoeachrotaryswitch.
Theassignedfunctionisactivatedwhenyoupresstherotaryswitch.
Thefollowingfunctionscanbeassigned:
None
Nospecicfunctionalityisassigned.
AutoTilt
Thisisan"on/off"function.WhenAutoTiltmodeisactivatedthebeamwill
automaticallychangeitstiltangleforeachtransmission("ping").Thecentre
ofthetiltsectorisdenedbythechosentiltanglejustbefore
theAutoTilt
modeisstarted.Thechosentiltsectorisshownonthetiltindicatorinthe
Horizontalviewusingashadedbackground.Thesectorandstepsettingsare
madeusingtheTiltfunctionontheMainmenu.
Zoom
Placethecursoranywhereintheview,right-clickandselectZoom.Onlyone
zoomlevelisprovided.SelectZoomonemoretimetorestoretheoriginal
view.
MenuOff
Thisisan"on/off"function.Unlessyouneedtomakefrequentchangesto
theoperatingparameters,youmaywanttohidethemenufromthedisplay
presentation.Thisgivesyoumorespaceforechoinformation.
OwnShip
ThisisthesamefunctionasPlaceOwnShipMarkerontheshortcutmenu.
Selectthisfunctiontoaddasquaresymboltothevessel’scurrentpositionin
theechopresentation.Theownshipmarkerisnowregardedasanobject.All
informationabouttheobjectisshownintheObjectsmenulistedas"OSM".
UseDeleteOwnShipMarkerontheshortcutmenutodeletethemarkerfrom
thecurrentview.
