110-0001063/A

ProcessorUnitrearpaneldescription:

NexcomNISE3900E

TherearpaneloftheProcessorUnitholdsthepowersocketandmultipleinterfaceports.

ADCpowersocket

BRemotecontrol

CSerialports(Thenumberandphysicallocationoftheserialportsmaydifferfrom

onecomputermodeltoanother .)

DEthernetRJ45connectors

EGraphicsadapter(DVI-D(DigitalVisualInterface))

FUSB3.0ports

GGraphicsadapter(HDMI(High-DenitionMultimediaInterface))

Ethernetconnectors

ThepurposeofeachEthernetconnectorispredened.

ETH1SimradConnect

UsethissocketforEthernetcommunicationwithotherSimradproducts.TheMk2

OperatingPanelmustbeconnectedtothisEthernetsocket.

ETH2Sonarroom/Transceiver

UsethissocketforEthernetcommunicationwiththerelevantsonarsystemunitin

thesonarroom.Itisveryimportantthatahigh-qualityEthernetcableisused.You

mustuseCAT-5ESTP(ShieldedTwistedPair)qualityorbetter.Usingcableswith

lowerbandwidthcapacitywillreduceperformance.

ETH3Shipnetwork

Usethissocketifyouwanttoconnectyoursonarsystemtotheship’slocalarea

network(LAN).

Cablelayoutandinterconnections
