442728/B
43
•Subnetmask:255.255.255.0
•Gateway:157.237.60.1
TosetuptheEthernetcommunication,youmustdenetheIPaddressforthepanel,and
identifytheProcessorUnitinthepanelsoftware.Thesesettingsallowyoutousemorethan
oneOperatingPanelontheProcessorUnit.YoucanalsocontrolmorethanoneProcessor
UnitfromasingleOperatingPanel.
TheIPandMACaddressesforyourProcessorUnitarecontainedinatextlenamed
IPandMACaddress.txt.Thelecontainstheproductname,IPaddressandMACaddressin
thefollowingformat(example):
ST90
157.237.60.14
AC:1F:6B:1D:42:E6
Ifthetextleismissingyoumustndtheinformationmanually.Wesuggestthatyoudo
this,andcreatethenecessaryfolderandtxtlebefore
youstartthesetupprocess.See
step1intheprocedure.
Note
IftheOperatingPanelfailstoestablishcontactwiththeProcessorUnititwilltimeoutand
switchitselfoffaftertwominutes.Whenthishappenstheblueindicatorlightstopsashing.
Procedure
Ifrequired,locatetheIPandMACaddressesontheETH1EthernetadapterintheProcessor
Unit.
1ObtaintheIPaddress.
TheIPandMACaddressesforyourProcessorUnitarecontainedinatextlenamed
IPandMACaddress.txt.Ifthetextleismissingyoumustndtheinformation
manually.
aInthebottom-leftcornerofyourdesktop,selecttheWindows
®
Startbutton.
bOnthemenu,selectSettings.
cObservethattheWindowsSettingsdialogboxopens.
dSelectNetwork&Internet.
eSelectChangeadapteroptions.
fSelecttherelevantnetworkadapter,thenright-clickandselectPropertiesonthe
short-cutmenu.
gOnthelistofconnections,selectInternetProtocol4(TCP/IPv4),andthen
Properties.
Secondaryprocedures
