Machine Configuration (continued)
2-13
1 Trash basket holds waste paper punched out.
2 Knob 1 can be turned to ease removal of mishandled paper.
3 Knob 2 can be turned to ease removal of mishandled paper.
4Stapler staples the copied sets.
5Dial can be turned to the left to move the stapler to the center for replacement of the
staple cartridge.
6 Staple holder is to be removed from the stapler when supplying staples.
7 Guide lever 1 opens to remove mishandled paper.
8 Guide lever 2 opens to remove mishandled paper.
1 Trash basket
2 Knob 1
3 Knob 2
6 Staple holder
8 Guide lever 2
7 Guide lever 1
4 Stapler
5 Dial
