2.1 Overview of this device
Serial exposure connection example
Exposure room
Table
(14) Access point
(15) I/F Cable
X-ray
(18) AeroDR
XG Cable
Tube
(12) AeroDR
Battery Charger2
Signal relay
Power supply
(7) Power Supply Unit
(5) Detector
Interface
Unit 2
(15) I/F Cable
(5) Detector Interface Unit 2
(1) DR Detector
(1) DR Detector
(10) Generator
Interface Unit 3
Wireless connectionWired connection Wireless connectionWired connection
Wall stand
Hub
(17) Image processing controller
X-ray device
operation panel
X-ray device
