4.1
LED display of respective devices
98
4.1.6 Detector Interface Unit/Detector Interface Unit 2
Display pattern Lighting color Status
- Shutdown condition
Green Operating and not connected to the DR Detector
Blue Operating and connected to the DR Detector
4.1.7 Power Supply Unit
: Power LED (blue)
Display pattern Status
Shutdown condition
Operating
