6. Periodical check Field Service Ver. 2.0 Mar. 2006

bizhub C250P

Maintenance

6.5.10 Cleaning of the Area around the Waste Toner Collecting Port

1. Remove the Waste Toner Box.

See P.29

2. Wipe the areas around the Waste

Toner Collecting Port [1] clean of

spilled toner and dirt using a soft

cloth dampened with water or alco-

hol.

6.5.11 Replacing the Ozone Filter

1. Holding onto the hook, remove the

Ozone Filter [1].

NOTE

• The Ozone Filter is supplied with

the Transfer Belt unit.

Replace it when replacing the

Transfer Belt Unit.

6.5.12 Replacing the Deodorant Filter

1. Holding onto the hook, take out the

Deodorant Filter [1].

NOTE

• The Deodorant Filter is supplied

with the Toner Cartridge (Black).

Replace it when replacing the Toner

Cartridge (Black).

4038F2C018DB

[1]

4038F2C019DA

4038F2C201AA

[1]

bizhub_C250P_Total.book 30 ページ２００６年３月２７日　月曜日　午前８時２８分
