Field Service Ver. 2.0 Mar. 2006 6. Periodical check
35
bizhub C250PMaintenance
6.6.4 Cleaning of the IDC/Registration Sensor 1, 2
1. Remove the Image Transfer Belt.
See P.32
2. Wipe the surface of the IDC/Regis-
tration Sensor 1, 2 [1] clean of spilled
toner and dirt using a soft cloth
dampened with water or alcohol.
6.6.5 Replacing the Toner Cartridge (C, M, Y, K)
A. Removal Procedure
1. Open the Front Door.
2. Pressing the Toner Cartridge Lock
Claw [1], pull it toward.
3. Pull the Toner Cartridge [2] toward to
remove it.
1
4038F2C608DA
[1]
[1]
4038F2C560DA
[1]
4038F2C538DA
[2]
bizhub_C250P_Total.book 35 ページ ２００６年３月２７日 月曜日 午前８時２８分
