19. PAPER SETTINGField Service Ver3.0 Nov.2006
bizhub PRO 1050/1050P 1050e/1050eP
19.3 Relationship between the optimum value and the control of each of setting items by paper brand (European paper) (for fusing hard roller)
NOTE
• This table lists the optimum setting values by paper brands checked for paper through by Konica Minolta. For other brands, it is scheduled that information is provided in due course upon completion of the paper through check.
1. Line speed and fusing temperature are decided by setting the paper type and paper weight.
2. Smoothness is a value measured by the Beck smoothness testing machine stipulated in the ISO 5627:1995, and the smaller the value, the coarser the paper grain. When the paper is not listed in this table and the setting condition of which can not be found, obtain the smoothness data from the paper manufacturer and select the type of paper according to the value
of smoothness.
3. Coated paper B: To be used when it is corresponding to overlay printing. For particulars, see chapter III "6.5 Overlay printing adjustment" in the Field Service.
Setting of the condition for paper feeding
NOTE
• When using high quality printing paper, be sure to select a setting direction in which there occurs less amount of curling after printing.
• Marked with *: Paper the classification of which of smoothness or weight has been changed from the viewpoint of performance.
Weight
Paper type
40 to 49 g/m
2
50 to 61 g/m
2
62 to 71 g/m
2
72 to 91 g/m
2
92 to 130 g/m
2
131 to 161 g/m
2
162 to 209 g/m
2
210 to 244 g/m
2
245 to 300 g/m
2
Tray/4
Coated A
(Smoothness: over 100sec)
PRIMASET115 (115g/m
2
)
Schneidersohne Business Paper
Color Copy (120g/m
2
)
RDEREY (160g/m
2
) RDEREY (200g/m
2
)
Line speed (mm/s) 290 290 425 490 490 490 490 490 425
Fusing temp. index (°C) -15 -15
-15 -10 Standard temp. +5 +5 +5 +5
Coated B
(Smoothness: over 100sec)
Line speed (mm/s) 290 290 425 490 490 490 490 490 425
Fusing temp. index (°C) -15 -15
-15. -10 Standard temp. +5 +5 +5 +5
Fine
(Smoothness: 50 to 100sec)
Clair Mail (60g/m
2
) Mondi Business Paper Color
Copy (200g/m
2
)
(NEU Color Copy (200g/m
2
))
PRIMASET (170g/m
2
)
Line speed (mm/s) 290 425 490 490 490 490 490 425 290
Fusing temp. index (°C) -15 -15 -15 -10 Standard temp. +5 +5 +5 +5
Normal
(Smoothness: 20 to 50sec)
Mondi CEETEE COPIER (60g/m
2
)
(NEU CEETEE COPIER (60g/m
2
))
Konicaminolta Profi (80g/m
2
)* Nautilaus (80g/m
2
)
NOPA Top (80g/m
2
)
Konicaminolta Original (80g/m
2
)
Konica Minolta Color + A4 (90g/
m
2
)
(NEU Color Copy (90g/m
2
))
REPEAT (80g/m
2
)
Turbocopy80 (80g/m
2
)
Turbocopy80 (SB,BB) (80g/m
2
)
AVERY DSP24
Plano Jet90 (90g/m
2
)
Line speed (mm/s) 490 490 490 490 490 490 425 290 290
Fusing temp. index (°C) -5 -5 -5 Standard temp. +5 +5 +5 +5 +5
Book/News
(Smoothness: 10 to 20sec)
Disable
BioTop3 (80g/m
2
)
Classic White (80g/m
2
)
Xerox3R91978 (160g/m
2
) Turbocopy (160g/m
2
)*
Line speed (mm/s) 490 490 490 425 425 290 290 290
Fusing temp. index (°C) Standard temp. Standard temp. Standard temp. +5 +5 +5 +5 +10
Embossed
(Smoothness: 5 to 10sec)
Disable
(A fusing performance is not securable.)
Line speed (mm/s) 490 490 425 290 290 290
Fusing temp. index (°C) Standard temp. +5 +5 +5 +10 +10
<Air assist setting> <Paper feed assist plate>
Halftone dot: Air ON Frame in a thick line: 4 paper feed assist plates used
No halftone dot: Air auto Frame in a thin line: No paper feed assist plate used
