Setup
3
200/250/350 3-53
LDAP Server Setting
LDAP server settings can be specified for the following.
Item Description
LDAP Server Name Enter the LDAP server name. Up to 16 characters can be en-
tered.
Server Address Enter the IP address or host name of the LDAP server. Up to 64
characters can be entered.
Search Base Specify the location on the LDAP server where searches are to
be started.
Up to 255 alphanumeric characters can be entered, excluding
^.
Authentication Setting Specify the authentication settings.
General Settings: Select the LDAP authentication method.
Login name: Enter if “General Settings” is set to “Anonymous”.
Up to 64 alphanumeric characters can be entered, excluding ^.
Password: Enter if “General Settings” is set to “Anonymous”.
Up to 32 alphanumeric characters can be entered, excluding ^.
Domain Name: Enter if “General Settings” is set to “GSS-SPNE-
GO”. Up to 64 alphanumeric characters can be entered, exclud-
ing ^.
Maximum number of search Specify the maximum number of hits to be received in an LDAP
search between 5 and 100.
Connection time out Specify a search timeout between 5 and 300 seconds.
SSL/TLS Select whether to perform encryption of the send data using
SSL/TLS.
Port Number Enter a number between 1 and 65535 for the port used to com-
municate with the LDAP server.
Initialize Setting Clears all of the settings that were entered. After the settings are
cleared, check the message, and then touch [Enter].
Check Connection Check the connection to the LDAP server, using the entered
settings.
To Next Page
