Konica Minolta CM-3600A - System Diagram

10
System Diagram
CM-S100w
Accessory Case
CM-A215
Dust Cover
CM-A110
Spectrophotometer
CM-3600A
ACAdapter
AC-A308
USBCables
IF-A21（3m）
USBCables
IF-A22（5m）
White Calibration
Plate CM-A139
(with CD-ROM containing
calibration data and
data-setting software)
Target Mask
CM-A107 (SAV)
(ø4 mm measurement /
ø7 mm illumination)
Transmittance
SpecimenHolder
CM-A96
CM-A100
Zero Calibration Box
CM-A104
(CM-3600A)
Target Mask
CM-A106 (MAV)
(ø8 mm measurement /
ø11 mm illumination)
Target Mask
CM-A105 (LAV)
(ø25.4 mm measurement /
ø30 mm illumination)
Cell
Cell
Professional Edition
Lite Edition
Personal Computer
CM-A130（2mm;setfor100）
CM-A131（10mm;setfor100）
CM-A132（20mm;setfor100）
CM-A97（2mm）
CM-A98（10mm）
CM-A99（20mm）
Standard accessories Optional accessories
SpectraMagic
TM
NX
Transmittance
ZeroCalibrationPlate
