Korg MicroKORG XL User Manual

microKORG XL
90
4. Front panel knob/button control
change assignments
Control changes can be assigned to each front panel knob/button of the
microKORG XL so that the changes in sound as controlled by knob/button
operations can be transmitted as performance data.
NOTE For details on assigning control changes to the microKORG XL ’s knobs
and buttons, refer to page 61 “CC MAP (MIDI Control Change No. Map)”.
NOTE Different parameters are assigned to synth parameters and vocoder pa-
rameters.
If you are using two microKORG XL units to transmit and receive
these parameters, you must set the transmitting and receiving pro-
grams to the same settings.
Page Parameter Initial Value (transmitted) Value (received)
UNISON
MODE CC#03 0...31: OFF, 32...63: 2VOICE, 64...95: 3VOICE, 96...127: 4VOICE 0...31: OFF, 32...63: 2VOICE, 64...95: 3VOICE, 96...127: 4VOICE
PITCH PORTMNTO CC#05 0...127 0...127
OSC1
WAVE CC#08
0...15: SAW, 16...31: PULSE, 32...47: TRIANGLE, 48...63: SINE,
64...79: FORMANT, 80...95: NOISE, 96...111: PCM/DWGS,
112...127: AUDIO IN
0...15: SAW, 16...31: PULSE, 32...47: TRIANGLE, 48...63: SINE,
64...79: FORMANT, 80...95: NOISE, 96...111: PCM/DWGS,
112...127: AUDIO IN
OSC MOD CC#09
0...31: WAVEFORM, 32...63: CROSS, 64...95: UNISON, 96...127:
VPM
0...31: WAVEFORM, 32...63: CROSS, 64...95: UNISON, 96...127:
VPM
OSC1.C1 CC#15 0...127 0...127
OSC1.C2 CC#17 0...127 0...127 (OSC MOD=VPM: 1...32:0...127)
OSC2
WAVE CC#18 0...31: SAW, 32...63: PULSE, 64...95: TRIANGLE, 96...127: SINE 0...31: SAW, 32...63: PULSE, 64...95: TRIANGLE, 96...127: SINE
OSC MOD CC#19 0...31: OFF, 32...63: RING, 64...95: SYNC, 96...127: RING.SYNC 0...31: OFF, 32...63: RING, 64...95: SYNC, 96...127: RING.SYNC
SEMITONE CC#20 J p. 41 “SEMITONE (Oscillator 2 Semitone)” J p. 41 “SEMITONE (Oscillator 2 Semitone)”
TUNE CC#21 0...127 0...127
MIXER
OSC1 LVL CC#23 0...127 0...127
OSC2 LVL CC#24 0...127 0...127
NOISE.LVL CC#25 0...127 0...127
FILTER1
CUTOFF CC#74 0...127 0...127
RESO CC#71 0...127 0...127
TYPE BAL CC#27 J p. 92 ““TYPE BAL” values” J p. 92 ““TYPE BAL” values”
ROUTING1 CC#26
0...31: SINGLE, 32...63: SERIAL, 64...95: PARALLEL, 96...127:
INDIV
0...31: SINGLE, 32...63: SERIAL, 64...95: PARALLEL, 96...127:
INDIV
EG1 INT CC#79 0/1: –63, 2: –62...63: –1, 64: 0, 65: +1...127: +63 0/1: –63, 2: –62...63: –1, 64: 0, 65: +1...127: +63
KEY TRK CC#28 0/1: –2... 64: 0...127: +2 0/1: –2... 64: 0...127: +2
