Korg sampler User Manual

154
Options
* Appearance and specifications of this product are subject to
change without notice. (March/’02)
User interface TouchView graphical user interface (320 × 240 pixel LCD display)
[VOLUME] slider
Mode keys [COMBI], [PROG], [SEQ], [SAMPLING], [S.PLAY], [GLOBAL], [DISK]
Value controllers [VALUE] slider, [VALUE] dial, [ ][ ] keys, numeric keys ([0]...[9], [–], [./10’s HOLD],
[ENTER])
[MENU] key, [EXIT] key, [COMPARE] key
BANK keys [INT-A], [INT-B], [INT-C], [INT-D], [INT-E], [INT-F], [INT-G],
[EXB-A], [EXB-B], [EXB-C], [EXB-D], [EXB-E], [EXB-F], [EXB-G]
SEQUENCER keys [PAUSE], [REW], [FF], [LOCATE], [REC/WRITE], [START/STOP]
SAMPLING keys [REC], [START/STOP]
Audio outputs AUDIO OUTPUT (MAIN) L/MONO, R
AUDIO OUTPUT (INDIVIDUAL) 1, 2, 3, 4
Output impedance 1.1 [kΩ] (L/MONO is 550 [Ω] for mono)
Maximum output level +13.5 [dBu]
Load impedance 100 [kΩ] or greater
AUDIO OUTPUT HEADPHONE Output impedance 33 [Ω]
Maximum output level 25 [mW]
Load impedance 33 [Ω]
S/P DIF Connector: optical, Format: 24-bit S/P DIF (IEC60958, EIAJ CP-
1201), Sample rate: 48 kHz, 96 kHz selectable
Audio inputs AUDIO INPUT 1, 2
LEVEL [MIC/LINE] switch, [LEVEL] knob
Input impedance 10 [kΩ]
Nominal level LINE: +4 [dBu] @ [LEVEL] knob= min.
–30 [dBu] @ [LEVEL] knob= max.
MIC: –17 [dBu] @ [LEVEL] knob= min.
–52 [dBu] @ [LEVEL] knob= max.
Maximum level LINE: +14 [dBu] @ [LEVEL] knob= min.
–20 [dBu] @ [LEVEL] knob= max.
MIC: –7 [dBu] @ [LEVEL] knob= min.
–42 [dBu] @ [LEVEL] knob= max.
Source impedance 600 [Ω]
S/P DIF Connector: optical, Format: 24-bit S/P DIF (IEC60958, EIAJ CP-
1201), Sample rate: 48 kHz, 96 kHz selectable
Control inputs DAMPER (half-damper supported), ASSIGNABLE SWITCH/PEDAL
Internal hard drive 5 Gbyte
Other MIDI IN, OUT, THRU, SCSI connector (D-sub half-pitch 50 pin), LCD contrast knob, 3.5 inch floppy disk drive, AC
power inlet, power switch, Calendar backup battery
Support for options EXB-PCM series PCM expansion board (16 Mbytes ROM) slots × 7
72 pin SIMM memory slots × 3 (for user sample memory)
CDRW-1, EXB-MOSS, EXB-DI, EXB-mLAN
Dimensions
(W × D × H)
88Keys: 1475 × 440 × 146 (mm) Inches: 58.07" × 17.32" × 5.75",
76Keys: 1311 × 382 × 129 (mm) Inches: 51.61" × 15.04" × 5.08",
61Keys: 1104 × 382 × 129 (mm) Inches: 43.46" × 15.04" × 5.08"
Weight 88 Keys: 29.7 kg/65.48lbs., 76 Keys: 19.6 kg/43.21lbs., 61 Keys: 17.2 kg/37.92lbs.
Power supply AC Local Voltage
Power consumption 38 W
Included items AC cable, Preloaded program disks TNSFD-00P, Installation plate for EXB-mLAN
Expansion boards
EXB-MOSS (DSP Synthesizer Board)
EXB-DI (Digital Interface Board)
EXB-mLAN (mLAN Interface Board)
EXB-PCM series
EXB-PCM01: Piano/Classic Keyboards
EXB-PCM02: Studio Essentials
EXB-PCM03: Future Loop Construction
EXB-PCM04: Dance Extreme
EXB-PCM05: Vintage Archives
EXB-PCM06/07: Orchestral Collection
EXB-PCM08: Piano
The multisamples of the EXB-PCM08 are built into the TRI-
TON STUDIO.
CD-R/RW drive CDRW-1
Expression/volume pedal XVP-10
Foot controller EXP-2
Damper pedal DS-1H
Pedal switch PS-1
Other MIDI cable
