13
Introduction
FeaturesFront &
rear panel
LCD screenConnectionsBasics
Basic concepts
Overview of the modes
The TRITON STUDIO has a large number of functions
that let you play and edit programs and combinations,
record and play sequence data, record and play back sam-
ples, and manage data on disk. The largest unit used to
organize these functions is called a mode.
The TRITON STUDIO has seven modes.
Program mode
• Select and play programs
You can choose programs from rewritable banks INT-
A–INT-F and EXB-A–EXB-G which contain a total of
1,664 programs, and non-rewritable bank INT-G (256
programs compatible with the GM2 standard, and nine
drum programs).
(The 128 programs of bank INT-F can be selected only
if the EXB-MOSS option has been installed.)
• Sample or resample.
For example you can sample an external audio source
while listening to the performance of the arpeggiator,
or resample a performance you play using a program.
• Edit a program
Make settings for the oscillator, filter, amp, EG, LFO,
effects, and arpeggiator.
The following multisamples are available for the oscil-
lator.
• 429 internal multisamples (ROM, Piano)
• Expanded multisamples (when one or more EXB-
PCM series board are installed)
• Multisamples (RAM) that you sampled on the
TRITON STUDIO or loaded in from media
• Create drum programs using a drum kit (created in
Global mode)
Combination mode
• Select and play combinations
A combination is a set of two or more programs (a
maximum of eight), and allows you to produce com-
plex sounds that could not be created by an individual
program.
You can choose combinations from rewritable banks
INT-A–INT-E and EXB-A–EXB-G which contain a total
of 1,536 combinations.
• Sample or resample.
For example you can sample an external audio source
while listening to the performance of the arpeggiators,
or resample a performance you play using a combina-
tion.
• Edit a combination
Make settings for volume, pan, layer/split etc. for each
timbre (program), and make settings for effects and the
two arpeggiators.
DISK MODE
IFX 1
IFX 2
IFX 3
IFX 4
IFX 5
MFX 1
MFX 2
MEQ
Insert / Master Effect
Arpeggiator
OSC 1
Multisample - H
Drum Kit
Multisample - L
PITCH1
FILTER1 AMP1
OSC 2
Multisample - L
PITCH2
FILTER2
AMP2
Multisample - H
PROGRAM
PROGRAM
IFX 1
IFX 2
IFX 3
IFX 4
IFX 5
MFX 1
MFX 2
MEQ
TRACK 1
TRACK 8
TRACK 2
TRACK 3
TRACK 4
TRACK 5
TRACK 6
TRACK 7
PROGRAM
PROGRAM
PROGRAM
PROGRAM
PROGRAM
PROGRAM
PROGRAM
Insert /Master Effect
Arpeggiator - A
Arpeggiator - B
SEQUENCER / SONG PLAY
PROGRAM
TRACK 9
TRACK 16
TRACK 10
TRACK 11
TRACK 12
TRACK 13
TRACK 14
TRACK 15
PROGRAM
PROGRAM
PROGRAM
PROGRAM
PROGRAM
PROGRAM
PROGRAM
PROGRAM
IFX 1
IFX 2
IFX 3
IFX 4
IFX 5
MFX 1
MFX 2
MEQ
TIMBRE 1
TIMBRE 8
TIMBRE 2
TIMBRE 3
TIMBRE 4
TIMBRE 5
TIMBRE 6
TIMBRE 7
PROGRAM
PROGRAM
PROGRAM
PROGRAM
PROGRAM
PROGRAM
PROGRAM
Insert /Master Effect
Arpeggiator - A
Arpeggiator - B
COMBINATION
GLOBAL MODE
Drumsample / Sample - L
Drumsample / Sample - H
Key
Assign
ARPEGGIATOR PATTERN
Preset Arpeggio
Pattern: P0 - 4
DRUM KIT
User Arpeggio
Pattern: U00 - 231
SAMPLING MODE
Multisample
Sample
Sample
Sample
Sample
Sample
Sample
Sample
IFX 1
IFX 2
IFX 3
IFX 4
IFX 5
Insert Effect
Multisample
AUDIO INPUT
1
S/P DIF IN
L
mLAN IN
1
AUDIO INPUT
2
S/P DIF IN
R
mLAN IN
2
CDRW-1
Ripping
Resampling
Resampling
CD-ROM Write Audio CD
Only SEQ
Hard Disk
Analog Audio
To Next Page
