2:1 OSC 1 (07: Sync Modulation)
Parameters
Prog.
Edit
P2
07: Sync Modulation
This uses the modulator as the master waveform and the carrier as the slave waveform (which will be
synchronized to the master).
When the master waveform begins a new cycle (i.e., the instant that it passes the zero point going
from negative to positive), the phase of the slave waveform is reset to 0, causing it to begin a new
cycle.
2–1a: Input
Input [OSC2(1), SubOSC, Noise, Filter1, Filter2]
Specifies the master waveform (modulator).
Slave [Saw, Square, Triangle, Sine]
Specifies the slave waveform.
Wave Edge [0…99]
Specifies the amount of high frequency harmonics for the slave waveform. As this value is decreased, the
sound will have less high-frequency harmonics, and as it approaches 0 the volume will also decrease.
Modulator Wave
(Master)
Carrier Wave
(Slave)
Sync Modulation
2–1a
