258
[H]: Hex, [D]: Decimal
2.RECOGNIZED RECEIVE DATA
2-1 CHANNEL MESSAGES
Status Second Third Description ( Use ..... ) ENA
[Hex] [H] [D] [H] [D]
8n kk (kk) xx (xx) Note Off A
9n kk kk) 00 (00) Note Off A
9n kk kk) vv (vv) Note On (vv)=1-127 A
An kk kk) vv (vv) Poly Key Pressure ( as AMS ) T,Q
Bn 00 00) mm (mm) Bank Select(MSB) ( for Prog/Combi change ) *1 P
Bn 01 01) vv (vv) Modulation1 ( as Joy Stick +Y ) C
Bn 02 02) vv (vv) Modulation2 ( as Joy Stick -Y ) C
Bn 04 04) vv (vv) Foot Pedal ( as AMS & FX Dmod Src = Pedal ) C
Bn 05 05) vv (vv) Portamento Time C
Bn 06 06) vv (vv) Data Entry (MSB) ( for RPC edit ) C
Bn 07 (07) vv (vv) Volume C
Bn 08 (08) vv (vv) Balance Control ( for Post IFX Panpot control ) *2 C
Bn 0A (10) vv (vv) Panpot C
Bn 0B (11) vv (vv) Expression C
Bn 0C (12) vv (vv) Effect Control 1 ( as FX Dmod Src = FX1 ) C
Bn 0D (13) vv (vv) Effect Control 2 ( as FX Dmod Src = FX2 ) C
Bn 10 (16) vv (vv) Multi Purpose Ctrl1 ( as AMS & FX Dmod Src = Ribbon ) C
Bn 11 (17) vv (vv) Multi Purpose Ctrl2 ( as AMS & FX Dmod Src = KnobM1 ) C
Bn 12 (18) vv (vv) Multi Purpose Ctrl3 ( as AMS & FX Dmod Src = Slider ) C
Bn 13 (19) vv (vv) Multi Purpose Ctrl4 ( as AMS & FX Dmod Src = KnobM2 ) C
Bn 14 (20) vv (vv) ( as AMS & FX Dmod Src = KnobM3 ) C
Bn 15 (21) vv (vv) ( as AMS & FX Dmod Src = KnobM4 ) C
Bn 20 (32) bb (bb) Bank Select(LSB) ( for Prog / Combi change ) *1 P
Bn 26 (38) vv (vv) Data Entry (LSB) ( for RPC edit ) C
Bn 40 (64) vv (vv) Hold1 ( as Damper) C
Bn 41 (65) ≤3F/≥40 (≤63/≥64) Portamento Off/On C
Bn 42 (66) ≤3F/≥40 (≤63/≥64) Sostenuto Off/On C
Bn 43 (67) vv (vv) Soft Pedal C
Bn 46 (70) vv (vv) Sound Controller 1 ( for Sustain Level control ) C
Bn 47 (71) vv (vv) Sound Controller 2 ( for Resonance/HPF Cutoff ctrl ) C
Bn 48 (72) vv (vv) Sound Controller 3 ( for Release Time control ) C
Bn 49 (73) vv (vv) Sound Controller 4 ( for Attack Time control ) C
Bn 4A (74) vv (vv) Sound Controller 5 ( for LPF Cutoff control ) C
Bn 4B (75) vv (vv) Sound Controller 6 ( for Decay Time control ) C
Bn 4C (76) vv (vv) Sound Controller 7 ( for LFO1 Speed control ) C
Bn 4D (77) vv (vv) Sound Controller 8 ( for LFO1 Pitch Depth control ) C
Bn 4E (78) vv (vv) Sound Controller 9 ( for LFO1 Delay control ) C
Bn 4F (79) vv (vv) Sound Controller 10 ( for Filter EG Intensity ctrl ) C
Bn 50 (80) vv (vv) Multi Purpose Ctrl5 ( as AMS & FX Dmod Src = SW 1 ) C
Bn 51 (81) vv (vv) Multi Purpose Ctrl6 ( as AMS & FX Dmod Src = SW 2 ) C
Bn 52 (82) vv (vv) Multi Purpose Ctrl7 ( as AMS & FX Dmod Src = Foot SW ) C
Bn 53 (83) vv (vv) Multi Purpose Ctrl8 ( as AMS & FX Dmod Src = CC#83 ) C
Bn 5B (91) vv (vv) Effect 1 Depth ( for Send 2 Level control ) C
Bg 5C (92) 00/≠00 (00/≠000) Effect 2 Depth ( for Insert FX Off/On ) C
Bn 5D (93) vv (vv) Effect 3 Depth ( for Send 1 Level control ) C
Bg 5E (94) 00/≠00 (00/≠000) Effect 4 Depth ( for Master FX1 Off/On ) C
Bg 5F (95) 00/≠00 (00/≠000) Effect 5 Depth ( for Master FX2 Off/On ) C
Bn 60 (96) 00 (00) Data Increment ( for RPC edit ) C
Bn 61 (97) 00 (00) Data Decrement ( for RPC edit ) C
Bn 62 (98) ss (ss) NRPN Param No. (LSB)( for NRPN select ) *3 C
Bn 63 (99) tt (tt) NRPN Param No. (MSB)( for NRPN select ) *3 C
Bn 64 (100) 0r (0r) RPN Param No. (LSB) ( for RPN select ) *4 C
Bn 65 (101) 00 (00) RPN Param No. (MSB) ( for RPN select ) *4 C
Bn cc (cc) vv (vv) Control data ( for Seq. recording (cc)=0-101 ) C,Q
Bn 78 (120) 00 (00) All Sound Off C
Bn 79 (121) 00 (00) Reset All Controllers C
Bn 7A (122) 00/7F (00/127) Local Control Off/On A
Bn 7B (123) 00 (00) All Notes Off A
Bn 7C (124) 00 (00) Omni Mode Off ( as All Notes Off ) A
Bn 7D (125) 00 (00) Omni Mode On ( as All Notes Off ) A
Bn 7E (126) ≤10 (≤16) Mono Mode On ( as All Notes Off ) A
Bn 7F (127) 00 (00) Poly mode On ( as All Notes Off ) A
Cn pp (pp) -- -- Program Change ( for Prog/Combi change ) *1 P
Dn vv (vv) -- -- Channel Pressure ( as After Touch ) T
En bb (bb) bb (bb) Bender Change C
AMS : Alternate Modulation Source
FX Dmod Src : Effect Dynamic Modulation Source
n: MIDI Channel No. (0 - 15) •••••• Usually Global Channel.
When in Combination/Sequencer mode, each timbre's/track's channel.(Status is INT or BTH)
g: Always Global Channel No. (0 - 15)
x: Random
ENA : Same as Transmitted data
*1 : When Bank Map in Global mode is KORG;
MIDI In [Hex] Program Combination
mm,bb,pp = 00,00, 00 - 7F : Bank A 000 - 127 : Bank A 000 - 127
00,01, 00 - 7F : B 000 - 127 : B 000 - 127
00,02, 00 - 7F : C 000 - 127 : C 000 - 127
00,03, 00 - 7F : D 000 - 127
79,00, 00 - 7F : G 001 - 128
78,00, 00 - 7F : g(d) 001 - 128
38,00, 00 - 7F : G 001 - 128
3E,00, 00 - 7F : g(d) 001 - 128
When Bank Map in Global mode is GM;
MIDI In [Hex] Program Combination
mm,bb,pp = 3F,00, 00 - 7F : Bank A 000 - 127 : Bank A 000 - 127
3F,01, 00 - 7F : B 000 - 127 : B 000 - 127
3F,02, 00 - 7F : C 000 - 127 : C 000 - 127
3F,03, 00 - 7F : D 000 - 127
79,00, 00 - 7F : G 001 - 128
78,00, 00 - 7F : g(d) 001 - 128
00,00, 00 - 7F : G 001 - 128
38,00, 00 - 7F : G 001 - 128
3E,00, 00 - 7F : g(d) 001 - 128
3F,7F, 00 - 7F : Mute (KORG MUTE)
(XG) 00,01 - : Assign correspond program in G.
(GS) 01,00 - : Assign correspond program in G.
*2: When in Program/Sampling mode, Global channel.
When in Combination/Sequencer mode, IFX's channel.
*3: tt,ss = 00,02 : Arpeggiator Off/On
= 00,0A : Arpeggiator Gate control
= 00,0B : Arpeggiator Velocity control
When in Program/Combination mode, Global channel message is valid.
When in Sequencer mode, current selected track's channel message is valid.
Data Entry LSB value has no effect.
tt,ss = 01,08 : Vibrato Rate
tt,ss = 01,09 : Vibrato Depth
tt,ss = 01,0A : Vibrato Delay
tt,ss = 01,20 : Filter Cutoff
tt,ss = 01,21 : Filter Resonance
tt,ss = 01,63 : EG Attack Time
tt,ss = 01,64 : EG Decay Time
tt,ss = 01,66 : EG Release Time
tt,ss = 14,kk : Drum Filter Cutoff *
tt,ss = 15,kk : Drum Filter Resonance *
tt,ss = 16,kk : Drum EG Attack Time *
tt,ss = 17,kk : Drum EG Decay Time *
tt,ss = 18,kk : Drum Coarse Tune *
tt,ss = 19,kk : Drum Fine Tune *
tt,ss = 1A,kk : Drum Volume *
tt,ss = 1C,kk : Drum Panpot *
tt,ss = 1D,kk : Drum Rev Send(Send2) *
tt,ss = 1E,kk : Drum Cho Send(Send1) *
* Only valid when Part Mode is Drum, MDrm1 - Mdrm4.
kk: Drum Inst No. (0C - 6C = C0 - C8)
Data Entry LSB value has no effect.
*4: r = 0 : Pitch Bend Sensitivity ( Bend Range )
= 1 : Fine Tune ( Detune )
= 2 : Coarse Tune ( Transpose )
For drum program, both of Fine Tune and Coarse Tune affect to Detune.
Data Entry LSB value has no effect for Pitch Bend Sensitivity and Coarse Tune.
