Status Second Third Description ( Use for ..... )
[Hex] [H] [D] [H] [D]
2-2 SYSTEM COMMON MESSAGES
F2 ss (ss) tt (tt) Song Position Pointer ( Location ) *6
ss : Least significant [LSB]
tt : Most significant [MSB]
F3 ss (ss) Song Select ( Song or Cue List select ) *5
ss : Song(0-127)/Cue List(0-19) No.
2-4 SYSTEM EXCLUSIVE
2-4-1 UNIVERSAL SYSTEM EXCLUSIVE MESSAGE ( NON REALTIME )
DEVICE INQUlRY ( When received this message, transmits INQUlRY MESSAGE REPLY )
[F0,7E,nn,06,01,F7] 3rd byte nn : Channel = 0 - F : Global Channel
=7F: Any Channel
GM System On ( Receive when in Sequencer mode )
[F0,7E,nn,09,01,F7] 3rd byte nn : Channel = 0 - F : Global Channel
=7F: Any Channel
2-4-2 UNIVERSAL SYSTEM EXCLUSIVE MESSAGES ( REALTIME )
Master Volume
[F0,7F,0g,04,01,vv,mm,F7] 3rd byte g: Global Channel
6th byte vv: Value(LSB)
7th byte mm: Value(MSB)
mm,vv = 00,00 - 7F,7F : Min - Max
Master Balance
[F0,7F,0g,04,02,vv,mm,F7] 3rd byte g: Global Channel
6th byte vv: Value(LSB)
7th byte mm: Value(MSB)
mm,vv = 00,00:Left, 40,00:Center, 7F,7F:Right
Master Fine Tune ( Control Master Tune(cent) in Global )
[F0,7F,0g,04,03,vv,mm,F7] 3rd byte g: Global Channel
6th byte vv: Value(LSB)
7th byte mm: Value(MSB)
mm,vv = 20,00:-50, 40,00:+00, 60,00:+50
Master Coarse Tune ( Control Transpose (chromatic step) in Global )
[F0,7F,0g,04,04,vv,mm,F7] 3rd byte g: Global Channel
6th byte vv: Value(LSB)
7th byte mm: Value(MSB)
mm,vv = 34,00:-12, 40,00:+00, 4C,00:+12
2-3 SYSTEM REALTIME MESSAGES
Status[Hex] Description ( Use for..... )
F8 Timing Clock ( Tempo, AMS & FX Dmod Src ) *5
FA Start ( Seq Start & Arpeggiator Control ) *6
FB Continue ( Seq Continue start & Arpeggiator Control )*6
FC Stop ( Seq Stop & Arpeggiator Control ) *6
FE Active Sensing ( MIDI Connect check )
*5 Receive when MIDI Clock in Global mode is External MIDI or External USB.
*6 Receive when MIDI Clock in Global mode is External MIDI or External USB
and Receive Ext. Realtime Commands in Global mode is checked.
Receive when in Sequencer mode. (External Clock)
When in the Cue List page (Sequencer mode P2.1), respond to Location and No. of Cue List.
