Kracht GmbH Device description | 3
88046020002 11 / 46
3.3 Type key
Ordering example
VC 1 K 1 E 1 P 5 E 512
1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11.
Explanation of type key
1. Product name
2. Nominal size (Rated volume)
V
gz
0.025; 0.04; 0.1; 0.2; 0.4; 1; 3; 5; 12; 16
3. Bearing
K Ball bearing C Ball bearing (increased clearance )
H Hybrid ball bearing G Carbide plain bearing
4 .Material
1
Housing: EN-GJS-400-15 (GGG-40)
Gears: Steel
3
Housing: EN-GJS-600 (GGG-60)
Gears: Steel
2
Housing: Stainless steel
Gears: Stainless steel
4
Housing: Aluminium
Gears: Stainless steel (Nominal size
0.2)
5. Seal type
F FKM K FFKM
E EPDM Q FVMQ
P FEP
6. Surface
1 Standard (painted) 3 Without
2 Paint Skydrol resistant
7. Type of connection
P Plate structure R Pipe connection
8. Sensor system
2 2 Sensors 4
2 Sensors protected against vibra-
tion and condensation
1 1 Sensor 5 Encoder
3 Without Sensor system
9. Version of the sensor system
S Standard KX ATEX High temperature PLUS
H High temperature R Red. supply voltage
K High temperature PLUS L IO-Link
T Low temperature V Without Preamplifier
X ATEX E Encoder
10. Cable length
Without Cable 5 With 5 m Cable
