3 Overview
The FC-46xl HDMI Audio De-Embedder accepts an HDMI input signal,
de-embeds the audio signal from either the HDMI input or the audio return
channel (HDMI output), and transfers the audio signal simultaneously to:
• The HDMI output
• A digital audio S/PDIF output
• An optical TOSLINK
®
audio output
• An analog output
Note: When there are more than two channels
of audio (for example, 5.1), it
is available only on the digital outputs and the analog output is disabled.
In particular, the FC-46xl:
• Lets you connect your HDMI source to an HDMI display and enjoy
high quality digital audio at the same time (for example, when using a
high quality AV receiver)
• Features I-EDIDPro™ Kramer Intelligent EDID Processing™ an
Intelligent EDID handling and processing algorithm that ensures Plug
and Play operation for HDMI systems
• Features input format auto detection; digital RGB or YPbPr
• Supports resolutions up to 1080p@60Hz
• Supports deep color up to 36 bits per pixel at 1080p
• Is 5V DC fed
• Is HDCP compliant
3.1 About HDCP
The High-Bandwidth Digital Content Protection (HDCP) standard
(developed by Intel), protects digital video and audio signals transmitted over
DVI or HDMI connections between two HDCP-enabled devices to eliminate
the reproduction of copyrighted material. To protect copyright holders (such
as movie studios) from having their programs copied and shared, the HDCP
standard provides for the secure and encrypted transmission of digital
signals.
3.2 Defining EDID
The Extended Display Identification Data (EDID
1
1 Defined by a standard published by the Video Electronics Standards Association (VESA)
) is a data set provided by
a display, to describe its capabilities to an HDMI source. The EDID enables
the FC-46xl to identify what kind of display is connected to the output. The
