4. Using the Audio Source Selector button, select the audio source to be either
the HDMI input (button released, audio is taken from the Blu-ray Disc), or
the HDMI output (button pressed in, audio is taken from the TV audio return
signal).
5. Connect the 5V DC power adapter to the power socket and connect the
adapter to the mains electricity (not illustrated in
Figure 2
).
6 Technical Specifications
Table 2 defines the technical specifications
1
Table 2: Technical Specifications of the FC-46xl HDMI Audio De-Embedder
of the FC-46xl.
INPUT: HDMI Connector
OUTPUTS: 1 HDMI Connector
1 TOSLINK
®
optical digital audio connector
1 S/PDIF digital audio on an RCA connector
1 Analog audio on a 3.5 mm mini connector
OPERATION FREQUENCY: Supports up to 2.25Gbps (1080p @60Hz) 36 bit Deep Color
COMPLIANCE WITH HDMI STANDARD: Supports HDMI
2
CONTROLS:
, HDCP 1.4
Audio Source Select button
INDICATOR LEDS: ON, IN, OUT
POWER SOURCE: 5V DC 600mA
DIMENSIONS: 12.4cm x 7cm x 2.4cm (4.9" x 2.8" x 0.94") W, D, H
WEIGHT: 0.4kg (0.88lbs) approx.
ACCESSORIES: Power supply
OPTIONS: Kramer 10-Port Universal 5V Power Supply VA-100P-5
RK-3T 19” Rack Adapter
1 Specifications are subject to change without notice
2 Including audio return and deep color
