KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
10
6 Technical Specifications
Table 4 includes the technical specifications
1
of the TP-114.
Table 4: Technical Specifications of the TP-114 (with 100m CAT5 cable)
INPUT: 1 XGA on an HD15F connector
OUTPUTS: 1 XGA on an HD15F connector
4 RJ-45 OUT connectors
MAX. OUTPUT LEVEL: 1.8Vpp (XGA), 1.6Vpp (CAT5)
HIGHEST RESOLUTION
2
: UXGA, 1080P
DIFF. GAIN
2
: 0.03% (XGA), 7% (CAT5)
DIFF. PHASE
2
: 0.05° (XGA), 0.08° (CAT5)
K-FACTOR
2
: <0.05% (XGA), 0.3% (CAT5)
S/N RATIO
2
: 75dB (XGA), 73dB (CAT5)
CONTROLS
2
: 2 switches for sync inversion
COUPLING
2
: DC (XGA), AC (CAT5)
POWER SOURCE: 12 VDC 880mA
3
DIMENSIONS: 12cm x 7.15cm x 2.76cm (4.7" x 2.8" x 1.08"), W, D, H
WEIGHT: 0.3 kg. (0.67 lbs.) approx.
ACCESSORIES: Power supply
1 Specifications are subject to change without notice
2 For the TP-114 Transmitter/ TP-120 Receiver pair
3 Sufficient for feeding two receivers via CAT5
