3 Overview
The TP-141 and TP-142 are a high-immunity, extended-range twisted pair
transmitter and receiver for computer graphics video and unbalanced stereo
audio signals.
The TP-141 converts computer graphics video and audio inputs to twisted
pair signals, and the TP-142 converts the twisted pair signals back into
computer graphics video, unbalanced stereo and S/PDIF digital audio
signals. Together the TP-141 and TP-142 form a computer graphics
video/audio line transmitter/receiver system.
More specifically, the products feature:
Highest immunity from any kind of interference
Resolution exceeding UXGA
HDTV compatibility
Simultaneous unbalanced stereo and S/PDIF (24-bit 48kHz) audio
outputs (TP-142)
Level (gain) and EQ (peaking) controls (TP-142)
System range up to 250m (750ft) when using the Kramer
BCP-HDTP cable, or 600ft when using our standard skew free
cable, such the BC-XTP
Power Connect™ System - Only one unit in a system, the
transmitter or the receiver, needs to be connected to a power
source when the devices are within 50m (150ft) of each other
Note: The TP-141 and TP-142 are not compatible with existing Kramer TP
units such as the TP-121, TP-122, and so on.
3.1 About the Power Connect Feature
The Power Connect feature applies as long as the cable can carry power. The
distance does not exceed 50 meters on standard CAT 5 cable, for longer
distances, heavy gauge cable should be used
1
.
For a CAT 5 cable exceeding a distance of 50 meters, separate power supplies
should be connected to the transmitter and to the receiver simultaneously.
1 CAT 5 cable is still suitable for the video/audio transmission, but not for feeding the power at these distances
