KRAMER: SIMPLE CREATIVE TECHNOLOGY
Connecting the TP-581T, TP-582T and TP-582R
16
5.7 Acquiring the EDID
To acquire the EDID, connect the transmitter and receiver system as described
in Section 5.
Once the power is connected, the system acquires the EDID according to
the following priorities:
 If only one output is connected, the EDID will be acquired from that output
 If both outputs are connected, the EDID will be acquired from the
output connected to HDMI OUT 1
 If no output is connected, the default EDID is acquired
To acquire the EDID of a newly connected output:
1. Disconnect the power on the TP-582R.
2. Connect the new acceptor (to HDMI OUT 1, if two outputs are
connected).
3. Connect the power.
The EDID is acquired only if the power is disconnected and then reconnected
