TP-583Txr, TP-583Rxr, TP-583T, TP-583R – Technical Specifications
10
Technical Specifications
TP-583Txr and TP-583Rxr
TP-583Txr
Input
HDMI
On a female HDMI connector
Output
HDBT
On an RJ-45 connector
Port
RS-232
On a 3-pin terminal block connector for serial link extension
IR
On a 3.5mm mini jack connector
TP-583Rxr
Input
HDBT
On an RJ-45 connector
Output
HDMI
On a female HDMI connector
Port
RS-232
On a 3-pin terminal block connector for serial link extension
IR
On a 3.5mm mini jack connector
General
Video
Transmitted Data
Bandwidth
Up to 18Gbps (6Gbps per graphic channel)
Max Resolution
Standard compression level
4096x2160@60Hz (4:4:4) 24bpp
High compression level
3840x2160@60Hz (4:4:4) 24bpp
Compliance
HDCP 2.2, HDR 10
Reach
Extension
We recommend that you use Kramer shielded cables to achieve optimum extension ranges
(see www.kramerav.com/product/TP-583Txr).
Standard Compression
Level
Up to 100m (330ft) at 4K@60Hz (4:4:4), 4K@60Hz (4:2:0) or
4K@30Hz (4:4:4)
Up to 180m (590ft) at full HD (1080p @60Hz 24bpp)
High Compression Level
Up to 100m (330ft) at 4K@60Hz (4:4:4), or 4K@60Hz (4:2:0)
Up to 180m (590ft) at 4K@30Hz (4:4:4)
Up to 200m (650ft), full HD (1080p @60Hz 24bpp)
Compliance
HDBaseT 1.0
Extended
RS-232
Baud Rate
300 to 115200
Extended IR
Frequency
20kHz to 100kHz
Controls
Front Panel
IN, OUT, LINK and ON LED indicators
Rear Panel
DIP-switches
Power
Consumption
12V DC, TP-583Txr 400mA; TP-583Rxr 600mA
Source
12V DC, 2A
Environmental
Conditions
Operating Temperature
0° to +40°C (32° to 104°F)
Storage Temperature
-40° to +70°C (-40° to 158°F)
Humidity
10% to 90%, RHL non-condensing
Regulatory
Compliance
Safety
CE, UL
Environmental
RoHs, WEEE
Enclosure
Size
Tool
Type
Aluminum
Cooling
Convection ventilation
General
Net Dimensions
(W, D, H), each
12cm x 7.2cm x 2.4cm
(4.7" x 2.8" x 0.94")
Shipping Dimensions
(W, D, H)
15.7cm x 12cm x 8.7cm
(6.2" x 4.7" x 3.4")
Net Weight, each
0.2kg (0.44bs) approx.
Shipping Weight
0.72kg (1.6lbs) approx.
Accessories
Included
1 Power adapter, 1 power cord and 1 bracket set per device
Specifications are subject to change without notice at www.kramerav.com
