TP-583Txr, TP-583Rxr, TP-583T, TP-583R – Introduction
2
Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to reduce
the amount of WEEE sent for disposal to landfill or incineration by requiring it to be collected
and recycled. To comply with the WEEE Directive, Kramer Electronics has made
arrangements with the European Advanced Recycling Network (EARN) and will cover any
costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on
arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular
country go to our recycling pages at www.kramerav.com/support/recycling.
Overview
The devices described in this user manual are generally referred to as TP-583Txr (HDMI
Line Transmitter) and/or TP-583Rxr (HDMI Line Receiver) or generally an extender. A
device is named specifically only when a device-specific feature is described.
Congratulations on purchasing your Kramer TP-583Txr, TP-583Rxr, TP-583T and/or
TP-583R.
TP-583Txr / TP-583Rxr are a high-performance, HDBaseT transmitter/receiver system for 4K
HDR HDMI™, RS-232 and IR signals over twisted pair.
TP-583Txr converts all input signals into the transmitted HDBaseT signal. TP-583Rxr
converts the HDBaseT signal and outputs it to its HDMI and control ports.
The extenders are compatible with standard HDBaseT-compliant extenders up to 4K@30Hz
(4:4:4) video resolutions.
TP-583Txr and TP-583Rxr extend video signals up to 100m (330ft) at 4K@60Hz (4:4:4)
video resolution, up to 180m (590ft) at 4K@30Hz (4:4:4), and up to 200m (650ft) at HD video
resolution over Kramer copper cables.
TP-583T and TP-583R extend video signals to up to 70m (230ft) at up to 4K@60Hz (4:4:4)
video resolutions, over Kramer copper cables.
The extenders provide exceptional quality, advanced and user-friendly operation, and flexible
control.
Exceptional Quality
• High Performance Standard Extender – Professional HDBaseT extender for providing
long-reach signals over twisted-pair copper infrastructures. It employs low-level video
compression technology that delivers visually lossless performance for 4K@60 (4:4:4)
and HDR signals with near-zero latency. This high-quality compressed signal is
extended to almost double the extension reach of the uncompressed signal.
• I-EDIDPro™ Kramer Intelligent EDID Processing™ – Intelligent EDID pass-through
algorithm that ensures plug and play operation for HDMI source and display systems.
• Multi-channel Audio Extension – Up to 32 channels of digital stereo uncompressed
signals for supporting studio-grade surround sound.
