Kramer VM-114H2C User Manual

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
16
7 Technical Specifications
Table 3 includes the technical specifications
1
Table 3: Technical Specifications of the VM-114H2C
of the VM-114H2C.
INPUTS: 1 HDMI Connector
1 TP on an RJ-45 Connector
OUTPUTS: 2 HDMI Connectors
2 TP on RJ-45 Connectors
BANDWIDTH: Up to 2.25Gbps bandwidth per graphic channel (HDMI), 1.65Gbps bandwidth
per graphic channel (DGKat)
COMPLIANCE WITH
HDMI STANDARD:
Supports HDMI and HDCP
CONTROLS: Input select button, EDID select button, panel lock button, RS-232, local and
remote IR controls
INDICATOR LEDs: IR communication, Power, IN 1 HDMI, IN 2 CAT5, OUTPUT 1, 2, 3 and 4
POWER CONSUMPTION: 12V DC, 1.4A
OPERATING
TEMPERATURE:
0° to +55°C (32° to 131°F)
STORAGE
TEMPERATURE:
-45° to +72°C (-49° to 162°F)
HUMIDITY: 10% to 90%, RHL non-condensing
DIMENSIONS: 21.5cm x 16.3cm x 4.4cm (8.5in x 6.4in x 1.7in) W, D, H
WEIGHT: 0.9kg (1.98lbs) approx.
ACCESSORIES: Power supply, RC-IR3 infrared remote control transmitter
OPTIONS: HDMI/HDMI male-to-male cables, RK-1 19” rack adapter
8 Default Communication Parameters
Table 4 lists the default communication parameters for the VM-114H2C.
Table 4: Default Communication Parameters
RS-232
Protocol 2000
Baud Rate: 9600
Data Bits: 8
Stop Bits: 1
Parity: None
Command Format: HEX
Example (Output 1 to Input 1): 0x01, 0x81, 0x81, 0x81
1 Specifications are subject to change without notice
