2. SPECIFICATIONS
Models
VS-1211, VS-1011, VS-811, VS-611, VS-411, VS-1201xl, VS-1001xlm, VS-801xlm, VS-
601xlm, VS-401xlm
Inputs
12, 10, 8, 6, 4 video - composite/single component, 1Vpp/75ohm on BNC connectors.
12, 10, 8, 6, 4 balanced/unbalanced audio, +4dBm/10kohm, on 2-part, snap fit terminal
blocks (for the "11" group only), or RCA connectors (for the "01xl/m" group only).
One external sync input (or composite video) 1Vpp/75ohm, on BNC connector.
One RS-232 DB-9 control socket, DB-9 socket (“to next”), RS-485 terminal block, DB-15
for remote connector.
Outputs
One video - composite/single component, 1Vpp/75ohm on BNC connector (VS-1211, VS-
1201xl), Three video 1Vpp/75ohm on BNCs (VS-1001xlm, 801xlm,601xlm, 401xlm.)
One audio – balanced/unbalanced audio, up to +28Vpp/50ohm (24dBm), on snap fit
terminal blocks (for the "11" group only) or RCA connector (for the 1201xl only), 3 sets
of stereo audio on RCAs (VS-1001xlm, VS-801xlm, VS-601xlm, VS-401xlm.)
Bandwidth
(Video)
250 MHz -3dB for VS-1211, VS-1011, VS-811, VS-611, VS-411, VS-1201xl.
400 MHz -3dB for VS-1001xlm, VS-801xlm, VS-601xlm, VS-401xlm.
Non-linearity
<0.1%.
S/N Ratio
>77dB.
Diff. Phase
0.03

Diff. Gain
0.04%
K-Factor
<0.05%
Bandwidth
(Audio)
55kHz, -0.ldB.
Audio S/N
Ratio
>95dB (unweighted)
2
nd
Harmonic
<0.003% (1kHz)
Audio THD +
Noise
0.013%
Audio
Crosstalk
-79dB
Video Controls
Bottom accessible trimmers for video gain (-1.2 to 1.8dB Luma), cable EQ. ( 0 to 1.3dB )
Dimensions
(W, D, H)
19" x 7" x 1U rack mountable
Weight
VS-1211
3.1kg
(~7lbs)
VS-1011
2.9kg
(~6.6lbs)
VS-811
2.9kg
(~6.5lbs)
VS-611
2.88kg
(~6.4lbs)
VS-411
2.68kg
(~5.9lbs)
VS-1201xl
3.1kg
(~7lbs)
VS-1001xlm
2.9kg
(~6.6lbs)
VS-801xlm
2.9kg
(~6.5lbs)
VS-601xl
m 2.88kg
(~6.4lbs)
VS-401xl m
2.68kg
(~5.9lbs)
Power
consumption
16VA 15VA 16.1VA 18.4VA 19.5VA 16VA 15VA 16.1VA 18.4VA 19.5VA
Power Source
230VAC, 50/60 Hz (115VAC U.S.A.)
