3. Secure mounting hardware
· Adjust direction of faucet body (2) so that the handle is on the right
side of the faucet. Tighten mounting nut (3C) until snug. Tighten
mounting screws (3D) with Phillips screwdriver until snug.
4. Attach spray hose and counterweight
· Connect spray hose (6) to supply hose (4). Install weight (8) on
lowest vertical point on spray hose (6).
