58
ClimTec
®
6.
• Push the platform onto the sixth rung of
the lower base frame.
• Make sure that the hatch is above the
lower part of the stairs.
• Lock the platform into place with the
locking bolts.
1 x Art.-No. 711007
!
5.
• Attach the GuardMatic-System
®
to the
second rung from the top of the lower
base frame.
• Secure the moveable diagonal braces on
the rungs with the locking bolts.
2 x Art.-No. 710673
inside
© KRAUSE-Werk GmbH & Co. KG 561066S
