Kreg Adaptive Cutting System Rip Guides User Manual

# NAME
A
Guide body
B
Large bolt, handle, square nut
C
Small bolt, handle, wedge, hex nut
D
Small bolt, handle
E
Leveling foot
F
Stop bar
G
Lens, lens screw
E
F
D
G
G
C
B
A
B
C
RIP-GUIDE COMPONENTS
ATTENTION:
!
This product is intended for use with the Kreg Adaptive Cutting System Plunge Saw + Guide
Track (Item # ACS2000). Rip Guides position a workpiece for cuts up to 13" wide.
WARNING:
!
When making cuts less than 1" wide, support the guide track with scrap stock the same
thickness as the workpiece to keep the track from tipping or deecting and exercise caution while cutting.
WARNING:
!
This product can expose you to chemicals including Acrylonitrile and other chemicals,
which are known to the State of California to cause cancer and reproductive harm. For more information
go to www.P65Warnings.ca.gov.
WARNING:
!
Drilling, sawing, sanding or machining wood products can expose you to wood dust, a
substance known to the State of California to cause cancer. Avoid inhaling wood dust or use a dust mask or other
safeguards for personal protection. For more information go to www.P65Warnings.ca.gov/wood.
